Starway 4axles Hydraulic Folding Gooseneck Lowboy Trailer
Specification
Dimension Overall length: 15+4m ~ Fool height : 1 m ( deck height ) ,Width: 3.5 m ~4.25 m, Floor height: 1m ~ (deck height)
Kerb weight: 19 T Structure: Hot-rolled (box type) beams HEA with welded ladder type cross-members suitable to withstand concentrate
d heavy loads. Axles & Suspension: Round beam with underslung mechanical suspension 4×13000 Kg BPW Brakes: Two-line air brakes with manual slack adjuster and automatic load sensing valve.
WABCO ABS
Rims: 7.5×15’’Disc rims (16+2) Tires: Size 10.00R15 (16+2) Trangle brand King Pin: Heavy duty 3.5” welded on 16mm sliding plate
Jost Landing Gear: Two-speed mechanical, with one side operation and suitable base plates Jost
Platform: Made of mild chequered steel 6-8mm welded on fortified cross members Retractable Gooseneck Hydraulic operated gooseneck hinged to trailer body shall be levelled with the ground for loading and unloading of equipment on front side, without the need of ramps of any kind. (Unit is powered by Diesel Engine).
Made of mild chequered steel 6mm welded on fortified cross members
Hydraulic Winch Sepson or Eq. 45Ton driven by Diesel engine (Common Engine for Gooseneck & Winch)
Rear stabilizer: Manual legs at front of tyres (optional)
Blasting & Painting Grit blasted to SA2.5, one coat of anti-corrosion primer followed by two coats of Enamel paint in one colour of customer’s choice
Electrical System Accessories 24-V, 7-pin female socket S & N type Mudguards with rubber flaps Rear combination lights with protection grill One toolbox without tools. Water tank Registration plate light Fire extinguisher box suitable for 6 kg Five side lamps on each side
Spare tyre basket- 2 spare wheel Side and rear reflectors.
Side ladder on each side of trailer LED flash Brake lamp & warning buzzer Heavy duty bumper & reflector
